Lecture Note 07 (L15, L16): DMA, IOMMU & GPU Memory; NUMA & HPC Optimization

Combines: Lecture L15 (DMA, IOMMU & GPU Memory Management) and Lecture L16 (NUMA Topology & HPC Memory Optimization).

How This Note Is Organized

  1. Part 1 — DMA & IOMMU: Direct Memory Access; cache coherency (coherent vs streaming); DMA-BUF; IOMMU and security; VFIO; GPU memory and zero-copy.
  2. Part 2 — NUMA: Non-uniform memory access; first-touch and placement; memory policies (bind, preferred, interleave); numactl and libnuma; AutoNUMA; multi-GPU and CPU–GPU affinity.

Part 1: DMA, IOMMU & GPU Memory Management

Context: Devices move data to/from RAM without CPU copies. The CPU must not see stale data (cache coherency). The IOMMU translates device addresses and restricts access; DMA-BUF shares one buffer across CPU, GPU, camera, display.

DMA (Direct Memory Access)

  • Device (NIC, NVMe, GPU, camera ISP) transfers data to/from system RAM autonomously. CPU programs descriptor (src, dst, length); device runs transfer; completion via IRQ or poll.
  • Without DMA: Device → CPU copy → RAM. With DMA: Device → DMA engine → RAM; CPU is free after submitting descriptor.

Cache Coherency: Coherent vs Streaming

  • Coherent DMA: dma_alloc_coherent() — uncached or hardware-coherent; CPU and device always see same data; no explicit sync. Use for small control/descriptor regions.
  • Streaming DMA: CPU uses cached memory; driver synchronizes explicitly:
  • DMA_TO_DEVICE: CPU wrote data → dma_map_single() flushes cache → device reads.
  • DMA_FROM_DEVICE: Device will write → after transfer, dma_unmap_single() invalidates cache → CPU reads. Between map and unmap the buffer is "owned" by the device — CPU must not touch it.
  • dma_map_sg / dma_unmap_sg for scatter-gather (fragmented buffers). Direction controls which cache op is used; wrong direction = silent corruption.

IOMMU (Input-Output MMU)

  • Sits between devices and memory bus. Translates IOVA (I/O Virtual Address) to physical address using per-device/group page tables.
  • Without IOMMU: Device can DMA to any physical address (security risk). With IOMMU: Only mapped IOVAs are allowed; unmapped access → fault.
  • Implementations: Intel VT-d, AMD-Vi, ARM SMMU (Jetson Orin). IOMMU groups: Devices behind same translation unit; for VFIO passthrough, whole group is assigned together.
  • Drivers usually use dma_map_* which uses IOMMU automatically; low-level iommu_map/iommu_unmap in framework code.

DMA-BUF & Zero-Copy Pipeline

  • DMA-BUF: Kernel abstraction to share one DMA buffer across subsystems (CPU, GPU, camera ISP, display). Exporter allocates and exports; importer attaches and maps for its device.
  • Lifecycle: Exporter creates buffer, gets fd; fd passed (e.g. Unix socket); importer dma_buf_get(fd), dma_buf_attach, dma_buf_map_attachment → sg_table with IOVAs for that device.
  • Zero-copy: V4L2 camera → DMA-BUF fd → CUDA importer → same physical pages for inference → display. No CPU copy; sync via DMA fence (dma_fence_wait). V4L2 supports V4L2_MEMORY_DMABUF; userspace passes fd in buffer.

GPU Memory & Unified Memory

  • Discrete GPU: dedicated VRAM; driver manages allocations and CPU↔GPU copies. Unified memory (e.g. Jetson): CPU and GPU share physical RAM; one address space; no explicit copy for shared buffers, but bandwidth and latency depend on placement.
  • Resizable BAR (SAM): GPU BAR1 can cover full VRAM; CPU can address all GPU memory (important for GPUDirect Storage, zero-copy).

Part 2: NUMA Topology & HPC Memory Optimization

Context: On multi-socket machines, memory attached to socket 0 is "local" to CPUs on socket 0 and "remote" to socket 1. Remote access has higher latency and lower bandwidth; placement of data and threads matters.

NUMA Architecture

  • Each socket (NUMA node) has local DRAM (lower latency, full bandwidth). Access to another node's DRAM goes over interconnect (QPI/UPI, Infinity Fabric) — ~2× latency, ~half bandwidth.
  • Discovery: numactl --hardware, lstopo, numastat, /sys/devices/system/node/nodeN/distance. Distance matrix: local = 10; remote often 20–40.

First-Touch and Placement

  • Default (first-touch): Page is allocated on the node of the CPU that first faults it. If main thread on node 0 initializes a buffer later used only by workers on node 1, every access is remote — silent slowdown.
  • Fix: Allocate (and fault) on the same node that will use the data: pin thread to node, set mempolicy, then malloc + memset; or use numa_alloc_onnode() / mbind(..., MPOL_MF_MOVE) to move pages.

Memory Policies & numactl

  • MPOL_DEFAULT: First-touch. MPOL_BIND: Only listed nodes; fail if full. MPOL_PREFERRED: Prefer one node; fallback. MPOL_INTERLEAVE: Round-robin across nodes (bandwidth-bound).
  • set_mempolicy (process); mbind (VMA; MPOL_MF_MOVE migrates existing pages).
  • numactl: --cpunodebind=0 --membind=0 ./app (bind CPU and memory to node 0); --interleave=all (interleave); --preferred=1 (prefer node 1).

libnuma & AutoNUMA

  • libnuma: numa_node_of_cpu(sched_getcpu()), numa_alloc_onnode(), numa_bind(), numa_set_membind(), numa_set_interleave_mask().
  • AutoNUMA: Kernel migrates "hot" pages to the node of the accessing CPU. Overhead (scan, TLB shootdown, migration); can cause tail latency spikes. Recommendation: Disable (numa_balancing=0) on RT and latency-sensitive inference; use explicit numactl/mbind.

Multi-GPU & CPU–GPU Affinity

  • GPUs are attached to one socket's PCIe root. CPU↔GPU traffic from the other socket crosses interconnect. Use nvidia-smi topo -m to see topology; bind process and memory to the node that owns the GPU(s) used.

Summary Tables

DMA: Coherent = uncached/coherent, no sync. Streaming = map (flush/invalidate) → device uses → unmap (invalidate/flush); CPU must not touch between map/unmap.

IOMMU: IOVA→PA; per-device/group; restricts DMA; VFIO exposes to userspace for passthrough.

NUMA: Local vs remote latency/bandwidth; first-touch; bind/preferred/interleave; numactl; disable AutoNUMA for RT.

AI Hardware Connection

  • DMA-BUF + V4L2: Zero-copy camera → GPU; fd over IPC. Streaming DMA direction must be correct (TO_DEVICE / FROM_DEVICE) to avoid corruption.
  • IOMMU: Security and isolation for GPU/VFIO; required for safe passthrough.
  • NUMA: Pin inference and weights to same node as GPU; first-touch on wrong node halves effective bandwidth. numastat -p to verify; disable AutoNUMA on inference servers.
  • Multi-GPU: Place processes and allocations on the node that owns the target GPU; use topology tools to avoid cross-socket PCIe.

Combines Lectures L15, L16 (DMA, IOMMU, GPU Memory; NUMA, HPC Optimization).
